inhalable dust continuous tester

1.Product overview of inhalable dust continue tester

inhalable dust continuous tester is used to evaluate dust, monitor inhalable dust, and measure dust (PM10 / PM2.5) concentration.This instrument is a new generation of intelligent measurement instruments that can be measured in real time and quickly in the air by real-time and rapid measurement of the concentration of inhalable particulate matter in the Center for Disease Control, Health Supervision, Environmental Monitoring and other departments.

This instrument is a portable direct reading measuring instrument for light scattering.It has the advantages of fast test speed, high sensitivity, good stability, light weight, low noise, simple operation, dual-purpose AC and DC.Especially suitable for measurement without external power supply.

inhalable dust continue tester is a high-performance instrument that introduces the most advanced laser technology to quickly and accurately measure respiratory dust particles (PM2.5PM10).It is an upgraded version of the PC series.This instrument has the characteristics of fast testing, accurate and stable, simple operation, convenient maintenance, noise-free pollution, and dual-purpose AC and DC for private car consignment.It is suitable for real-time monitoring of the Centers for Disease Control and Prevention, health supervision, environmental testing and other departments.

2.Inhalable dust continue tester application site

General production workshops, public places, disease control centers, health supervision, environmental monitoring and other departments

3.Inhalable dust continue tester main technical indicators

1.Large screen LCD display in Chinese, rich in content, LCD with blue backlight, convenient for night applications;

2.It has a built-in real-time clock, and the measurement data is stored with time, which is convenient for users' statistics and analysis;

3.The measurement data can be transmitted to the computer through the serial port to realize data export and printing;

4.Two monitoring indicators of PM10 and PM2.5 can be measured simultaneously;

5.Measurement range of inhalable particulate matter: 0.001~10mg/m³;

6.Relative measurement error: ≤±10%;

7.Detection sensitivity: 0.001mg/m³;

8.Sampling time: 1 minute

9.Data storage capacity: 50 pieces of data can be stored

10.Working power supply: Built-in lithium battery, AC and DC dual-purpose; the built-in battery can be measured continuously for 12 hours.

11.Working environment: temperature (0-55℃) humidity RH (20-80)%

12.Volume: 240mm×135mm×50mm;

13.Weight; about 500g;

4.Inhalable dust continue tester product features

Compared with other PC-3A series products, the upgraded instrument has the following significant features:

1.It can detect PM2.5 and PM10, and truly realize dual use of one machine;

2.Large screen LCD display in Chinese, rich display content, LCD with blue backlight;

3.It has a built-in real-time clock, and the measurement data is stored with time, which is convenient for users' statistics and analysis;

4.The measurement data can be transmitted to the computer through the serial port and the data can be printed through the computer.
