Insect Monitoring Light

1.Introduction to Insect Monitoring Light

Insect Monitoring Light monitors insects in real time, using continuous light technology to attract flying pests without the use of chemical pesticides.Working principle: Use optical, electrical, and CNC technologies to achieve functions such as insect luring, insect killing, and assembly.Under unsupervised conditions, system operations such as insect luring, insect killing, insect dispersion, photography, transportation, collection, and drainage can be automatically completed, and then wireless transmission technology and Internet of Things technology can be used to upload environmental meteorological and pest situations to the designated agricultural cloud platform in real time.

Main purpose: to analyze and predict the occurrence and development of pests, provide services for modern agriculture, and meet the needs of insect situation prediction and specimen collection.

2.Insect Monitoring Light main structure

Main machine material: spray plastic

Base: The base height is 320mm, used to prevent rainwater from pouring back into the central control box during rainy season

Louver: bird protection

Screen: 10.1-inch touch screen

Overall machine size: 710*600*2120mm (including base)

Components: insect trapping device, impact screen, insecticide device, high-definition camera, main control system, mechanical components, rain and snow sensor, light sensor, professional metal box frame

3.Insect Monitoring Light technical parameters

1.Meet the safety requirements and technical requirements in the GB/T 24689.1-2009 Plant Protection Mechanical Insect Measurement and Reporting Light Standard.

2.Automatically convey insects with conveyor belts and automatic cleaning

3.It can be set and controlled in different time periods, and it can be taken automatically and manually.

4.The insect body is evenly spread and spread on the conveyor belt.The conveyor belt can accurately send all the insect bodies collected to the shooting area of the high-definition camera device, and the insect bodies collected are vibrating and dispersed and flattened to ensure that the characteristics of each insect body are clearly photographed.

5.The working mode can be set remotely, wireless photography can be taken remotely and terminal device parameters can be set remotely.

6.Built-in GPS positioning function to view device sites and other data in the map.The device is stolen and can be traced.

7.Infrared insecticide, temperature control of far-infrared insect body treatment chamber: After working for 15 minutes, the temperature reaches 90±5℃, and the treatment time can be adjusted at will.

The mortality rate of far-infrared insect body treatment is not less than 98%, and the intact rate of insect body is not less than 95%.

8.Light control control: Automatically turn on the lights at night, automatically turn off the lights during the day (standby) and change the working state without being exposed to instantaneous strong light.

9.De-period control: Set working time periods according to the living habits of target pests.

10.Rain control system device: a separate drainage system structure that automatically discharges rainwater, effectively separates rainworms, so that there is no water accumulation in the box.

11.Power supply: Voltage fluctuation range: 220V±60V, with leakage protection device.

12.Lightning protection device: effectively prevent lightning strikes.

13.Various environmental parameter interfaces such as wind speed and direction, ground temperature and humidity, light, and rainfall can be added.

14.Network mode: Various networking methods: 4G and WIFI wired can be selected at will, and can be managed online anytime and anywhere.

15.The 800W pixel image acquisition device is built-in to collect images of insect bodies on the insect disk in real time through the camera.

4.Insect Monitoring Light installation method:

1.Determine the installation location of the insect detection equipment and prefabricate a cement platform of a certain thickness in advance..

2.Place the base on the cement platform and drill holes according to the fixing of the foot holes of the base.Two fixing holes are made for each fixing foot.

3.Embed the 8 expansion screws in the accessories into the punched holes, correspond to the base fixing holes with the 8 expansion screw holes, and tighten them with a wrench.

4.After confirming and testing that the base and cement platform are stable, lift the equipment onto the base, correspond to the installation hole position, and use screws to fix the equipment and the base.

5.Insect Monitoring Light insect information reporting platform:

The insect surveying and reporting platform is a system that integrates advanced technology and intelligent management.It is specially designed for agriculture, forestry and other ecological environment monitoring fields, aiming to improve the accuracy and efficiency of pest monitoring.The following is a detailed analysis of the main features of the platform:

1.Multi-role permission management and data isolation

Login and management by account: Ensure that different users (such as administrators, operators, data analysts, etc.) access corresponding data and functions according to their responsibilities and needs.

Fine-grained permission control: realizes precise control of data permissions and operation permissions, ensuring data security and privacy.

Inter-agency data isolation: Ensure data independence and security between agencies or departments to avoid information leakage or confusion.

2.Remote intelligent control function

Real-time status monitoring: Users can remotely view the various parameters and working status of Insect Monitoring Light, and promptly discover problems and deal with them.

Remote control operation: supports remote operations such as capture, manual/automatic mode switching, warehouse temperature setting, heating, insect transfer, working time setting, etc., to improve management efficiency.

Historical operation records: All control operations can be recorded and stored for easy traceability and auditing.

3.Self-trained AI algorithm and pest species recognition

AI algorithm self-training: The platform's built-in self-training AI algorithm can continuously learn and identify new pest species and adapt to pest changes in different regions and seasons.

Automatic recognition of pest species: Automatically analyze image data through AI algorithms to quickly and accurately identify pest species and reduce manual intervention.

4.AI analysis and manual correction

Automatic AI analysis: Use your own insect database to perform automatic AI analysis to quickly obtain preliminary results.

Manual correction: Users can review and correct the AI analysis results based on actual conditions to improve the accuracy and reliability of the analysis.

5.Multi-dimensional statistical analysis

Pest species statistics: Statistics are conducted on the monitored pest species to analyze the distribution and changing trends of different pests.

Quantity statistics: count the number of pests and evaluate the degree of pest hazard.

Regional analysis: Based on geographical location information, analyze the distribution characteristics and migration patterns of pests in different regions.

6.Support secondary development and system integration

API interface: Provides a Java-based API development interface to facilitate users to conduct secondary development or system integration according to their own needs.

System integration docking: Supports integrated docking with other agricultural management systems, meteorological systems, etc., to realize data sharing and linkage management.
