Home Weather Station

1.Introduction to Home Weather Station

Home Weather Station is a simple, accurate and affordable portable weather station that allows you to track rain, wind, temperature and other weather information.BQX8 Home Weather Station is a highly integrated, low-power, fast installation and easy for field monitoring.

The device supports wired, Bluetooth, GPRS and other transmission methods, is debug-free and can be quickly arranged.It is suitable for the acquisition of meteorological data such as short-term emergency meteorological observations and mobile meteorological monitoring.It is widely used in meteorology, agriculture and forestry, environmental protection, ocean, airport, port, scientific investigation, campus education and other fields.

The device uses an eight-element integrated sensor, which can observe real-time meteorological elements such as wind speed, wind direction, temperature, humidity, air pressure, pm2.5, pm10, noise, etc.The sensor shell is made of imported Stainless steel material, which is more effective in resisting salt spray and other environments, and the protection level reaches IP65 or above.

2.Home Weather Station product features

1.The hidden ultrasonic probe on the roof cover can avoid interference from rain and snow accumulation, and avoid natural wind shading☆

2.The principle is to transmit a continuous frequency conversion ultrasonic signal, and to detect the wind speed and direction by measuring the relative phase☆

3.Eight-element integrated sensor for wind speed, wind direction, temperature, humidity, air pressure, pm2.5, pm10, noise☆

4.Standard configuration: GPRS, Bluetooth, 485 to USB

5.Aluminum alloy bracket, retractable

6.Shock-absorbing protective trolley case, easy to carry

3.Technical parameters of Home Weather Station

1.Wind speed: measurement principle: ultrasonic wave, range: 0～60m/s, accuracy: 0.1m/s+0.01v, resolution: 0.1m/s;

2.Wind direction: measurement principle: ultrasonic wave, range: 0~360°, accuracy: ±2°, resolution: 1°;

3.Air temperature: measurement principle diode junction voltage method, range: -40-80℃, accuracy: ±0.3℃ (25℃), resolution: 0.01℃;

4.Air humidity: measurement principle capacitive type, range: 0-100%RH, accuracy: ±3%RH (20%~80%), resolution: 0.01%RH

5.Atmospheric pressure: measurement principle piezoresistive type, range: 300-1100hpa, accuracy: ±0.25%, resolution: 0.1hpa;

6.PM2.5: Range: 0-1000ug/m3, accuracy: ±10% (＜500 micrograms), resolution: 1ug/m3;

7.PM10: Range: 0-1000ug/m3, accuracy: ±10% (＜500 micrograms), resolution: 1ug/m3;

8.Noise: Range: 30-120dB, Accuracy: ±1.5dB, Resolution: 0.1dB;

9.Data storage: no less than 500,000 pieces;

10.Power consumption: 1.75W

11.Lithium battery: capacity 12000maH, battery life ≥50h, battery capacity display function

12.Total weight of the equipment: ≤5kg;

13.Layout time: 1 person, no more than 2 minutes to complete the layout;

14.The manufacturer has ISO quality management system, environmental management system and occupational health management system certification

15.The manufacturer has a computer software registration certificate

16.The manufacturer is a 3A credit enterprise

4.Introduction to Home Weather Station’s computer software

1.Software for receiving, storing, viewing and analyzing PC stand-alone version of data

2.Support serial port data reception, processing and display

3.Support json strings, modbus485 and other communication methods

4.You can set the storage time yourself.You can set the acquisition time yourself in modbus485 acquisition mode

5.Support self-service addition, deletion, and modification of monitoring parameters protocols, names, icons, etc.

6.Support data post-processing function

7.Support external running of javascript scripts

5.Introduction to Home Weather Station Android APP

1.Android stand-alone version of data reception, storage, viewing and analysis software

2.Support Bluetooth data reception

3.The software background reception and processing after the mobile phone is dormant

4.Automatically add the device to json data, modbus device supports scanning code to add the device

5.Support historical data viewing, analysis, and export tables, support curve display and single data point viewing.

6.Support data post-processing function

7.Support external running of javascript scripts

6.Introduction to Home Weather Station Cloud Platform

1.CS architecture software platform, supports direct observation of mobile phones and PC browsers without additional software installation.

2.Support multiple accounts and multiple devices to log in

3.Support real-time data display and historical data display dashboard

4.Cloud server and cloud data storage are stable and reliable, easy to scale, and load balancing.

5.Support SMS alarm and threshold settings

6.Support map display and viewing device information.

7.Support data curve analysis

8.Support data export table form

9.Supports data forwarding, HJ-212 protocol, TCP forwarding, http protocol, etc.

10.Support data post-processing function

11.Support external running of javascript scripts
