Automatic Total Sky Imager

1.Automatic Total Sky Imager product overview

Automatic Total Sky Imagerr is an automated camera system that provides daytime hemispheric sky images for measuring the proportion of the sky view that is covered by clouds.Automatic Total Sky Imager uses high-precision fisheye lenses to automatically record cloud-like distribution throughout the sky without sun occlusion device and direct sunlight, saving pictures of cloud distribution in the sky.The protective glass uses a hard coated dome to protect the lens from the weather and prevent sun exposure from damage to the CCD measuring element.

The equipment is simple to install and fully modularly installed.The equipment can adopt ventilation and heating devices, so that the imaging device will not be affected by weather changes.Analyze clear sky, hemisphere cloud cover, thick and thin clouds, artificial horizons covered by the horizon and cloud cover above the cloud cover.

The cloud bottom height software provides possibilities, and the cloud altitude and data (latitude, longitude and altitude) are evaluated in real time on site and stored with each individual CMS image.This product has dynamic analysis function, which can clearly record the distribution of cloud shape and cloud volume in the sky during the day, and automatically save it to the local machine for comparison and analysis, or upload it to the cloud to identify the cloud information through AI algorithms.It can be widely used in meteorology, civil aviation, transportation, marine research, smart cities and other fields.

The imager has a wide viewing angle of 175° and a high-resolution sensor, which can automatically record cloud conditions throughout the sky and convert it into quantitative cloud information through advanced cloud detection algorithms in the software.The imager can access the Internet through a standard network card and transmit data to a server or a monitoring computer through the network.

The imager control software integrates a horizon determination tool, providing users with flexibility and functional needs.For example, the software can set the zenith angle range, the ground object shielding area or the area of interest to avoid the impact of inherent masks around the station on the observation results.The imager also has good waterproofing.

2.Automatic Total Sky Imager product features

15 million pixel fisheye camera, real-time image acquisition

2.External TRH sensor

3.Maximum output of 2560×1920 30fps images

4.No sun blocking device, effectively record the cloud conditions in the sky

5.Built-in computer host, no additional workstation installation required

6.It can connect to the network, and can access multiple cloud platforms through remote operation and monitoring of terminals.

7.Low power consumption, small size, light weight, easy to install outdoor

8.It has waterproof function, can be used for all-weather observation
